HT–2/M/ZIRKON–120 - Furnace for sintering zirconium dioxide
Germany
Product code: 9650
12290 n.u.
HT–2/M/ZIRKON–120 - Furnace for sintering zirconium dioxide
12290 n.u.
THE HT SERIES
90 SINGLE CROWNS OR SINTERING DISC
- High purity molybdenum-disilicide heating elements PRO
- Max. temperature 1650°C
- Heating-chamber capacity 3x Ø 120/30 mm
- Program control (LCD-display, 4 stages, 30 program capacity)
- Service programs
A - Temperature control*
only in conjunction with test-kit
C-Purge heating chamber
E- Regenerate heating elements - Thermocouple PtRh-Pt, type S
- Temperature accuracy at 1500°C +/-3°C
- Timer function
Technical information | HT-2/M/ZIRKON-120 |
---|---|
Power max. | 3800 W |
Voltage range / frequency | 200-240 V / 50-60 Hz |
Weight | 74 kg |
Dimensions W/D/H | 500/560/820 mm |
Process capability | |
Max. temperature | |
Heating elements | |
Number of heating elements | 6 |
Heating-chamber height | 102 mm |
Max. heating-chamber capacity | 120/30 mm |
